Camera

Image Sensor

1/2.8” STARVIS™ CMOS

Pixels

4 MP

Max. Resolution

2560 (H) × 1440 (V)

Scanning System

Progressive

Electronic Shutter Speed

1/1 s–1/30,000 s

Minimum Illumination

Color: 0.005 [email protected];

B/W: 0.0005 [email protected];

0 [email protected] (IR on)

Illumination Distance

Distance up to 250 m (820 ft)

Illumination On/Off Control

Auto/Manual

Illuminator Number

6

Lens

Focal Length

3.95 mm–177.75 mm

Max. Aperture

F1.6–F4.95

Angle of View

H: 70.3°–1.8°; V: 37°–1°; D: 69.3°–2°

Optical Zoom

45x

Focus Control

Auto/Manual

Iris Control

Auto/Manual

Close Focus Distance

10 mm–3,000 mm

DORI Distance

DORI Distance

Detect

Observe

Recognize

Identify

3176 m

(10420 ft)

1271 m

(4170 ft)

635 m

(2083 ft)

318 m

(1043 ft)

PTZ

Pan/Tilt Range

Pan: 0°–360° endless; Tilt: -20°–90°,auto flip 180°

Manual Control Speed

Pan: 0.1°–260° /s; Tilt: 0.1°–120° /s

Preset Speed

Pan: 300° /s; Tilt: 200° /s

Presets

300

Tour

8 (up to 32 presets per tour)

Pattern

5

Pan

5

Power up Action

Auto restore to previous PTZ and lens status after power failure

Idle Motion

Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period

Protocol

DH-SD, Pelco-P/D (Auto recognition)

Artificial Intelligence

Perimeter Protection

Tripwire, Intrusion.

Support alarm triggering by target types(human

and vehicle)

Filtering out false alarms caused by animals, rustling leaves, bright lights, etc

Auto Tracking

Support

Video Structuralization

Support human, motor vehicle and non-motor vehicle image capture

SMD Plus

Support

Face Detection

Support

General Intellgence

Event Trigger

Motion detection, Video tampering , Scene

changing, Network disconnection, IP address

conflict, Illegal Access, Storage anomaly

General Intelligence

Object Abandoned/Missing

Video

Compression

H.265+/H.265/H.264+/H.264/MJPEG(Sub Stream)

Streaming Capability

3 Streams

Resolution

4M (2560 × 1440)/3M (2048 × 1536)/1080p (1920 ×

1080)/720p (1280 × 720)/D1 (704 × 576/704 × 480)/

CIF (352 × 288/352 × 240)

Frame Rate

Main stream: 4M/3M (1–25/30 fps), 1080p/1.3M/

720p (1–25/30 fps)

Sub stream1: D1/CIF (1–25/30 fps)

Sub stream2: 1080p (1–25/30 fps), 720p (1–25/30 fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.265/H.264: 3 Kbps–20,480 Kbps

Day/Night

Auto (ICR) / Color / B/W

BLC

Support

WDR

120 dB

HLC

Support

White Balance

Auto, ATW, Indoor, Outdoor, Manual

Gain Control

Auto / Manual

Noise Reduction

Ultra DNR (2D/3D)

Motion Detection

Support

Region of Interest

Support

Image Stabilization

Electronic

Defog

Support

Digital Zoom

16x

Flip

180°

Privacy Masking

Up to 24 areas

Audio

Compression

G.711a/G.711Mu/AAC/G.722 / G.726/G.729/MPEG2-L2

Network

Ethernet

RJ-45 (10Base-T/100Base-TX)

Protocol

IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP,

ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, RTCP, RTSP, RTMP, RTP, SMTP, NTP, DHCP, DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x

Interoperability

ONVIF Profile S&G&T, API

Streaming Method

Unicast / Multicast

User/Host

20 users

Storage

NAS (Network Attached Storage),Local PC for instant recording, Micro SD card 256GB

Browser

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, DMSS

Smart Phone

IOS, Android

Certifications

Certifications

CE: EN55032/EN55024/EN50130-4

FCC: Part15 subpartB,ANSI C63.4- 2014

Port

RS485

1

Audio I/O

1 (Line in; bare wire)/1 (Line out; bare wire)

Alarm I/O

7/2

Power

Power Supply

DC 24 V/2.5 A ± 25%; PoE+(802.3at)

Power Consumption

13 W, 26 W (IR On, Heater On)

Environment

Operating Conditions

–40 °C to 70 °C (–40 °F to +158°F) / Less than 95% RH

Protection

IP67, IK10

Structure

Casing

Metal

Dimensions

φ209 × 337.4 mm

Net Weight

5.9 kg (13 lb)

Gross Weight

9.6 kg (21.16 lb)
